Baking & Curing

Industrial Ovens

background shape

Preheating, drying, curing or burn-off, we have your Elite finishing addition

While it is an asset, having an oven as part of the process is not a must, which is why it is an Elite product on our Essential/Advanced/Elite scale. If consistency, quality and cycle time matter, adding an oven with efficient heat transfer technology and even distribution can be worth the expense.

With each build, the product line dictates the oven. From Batch Process, designed for industrial and manufacturing needs, to Batch Powder Coating created for small to medium size powder coating applications, to Batch Burn-Off made to safely and efficiently remove baked-on paint, powder coating, epoxies, lacquers, urethanes and other compounds from racks, hooks, fixtures and parts.

Features

  • Uni-flow air distribution system
  • 20-gauge aluminized steel
  • 4 inches of 4-pound mineral wool batt
  • PLC-based control system
  • 12-gauge formed steel support structure
  • Equipped for natural gas or propane
  • Top- or rear-mounted heat chamber
  • Standard temperature range is 300 to 500 degrees Fahrenheit
  • Gas supply pressure from 2 PSIG to 5 PSIG
  • Airflow switches and interlocks
  • NFPA, ETL, UL/CUL compliant
  • Sheet metal or insulated floor
  • Exhaust duct components
  • Oven cart or truck tracks
  • Door limit switches
  • White pre-coated panels
  • 6-pound mineral wool batt for heat retention

Features

  • Temperature of 750 degrees Fahrenheit
  • Fully automated system
  • Central heat distribution system
  • Primary and secondary water suppression systems
  • NFPA, ETL, UL/CUL compliant
  • Stainless steel oven interior
  • Track & Cart selections
  • Temperature indicating package chart recorder (dual pen)

Features

  • Uni-flow air distribution system
  • Converge control panel features advanced time and temperature control
  • 20-gauge aluminized steel
  • 4 inches of 4-pound mineral wool batt
  • Steel support structure
  • Direct gas-fired burner (natural gas or propane)
  • Top-mounted heater
  • Standard temperature range: 300-500 degrees Fahrenheit
  • NFPA, ETL, UL/CUL compliant
